CLEARANCE – Hikvision DS-2CD2387G2-LU 8MP ColorVu Turret IP Camera 2.8mm (H)
26/02/2026Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter Dome Camera 2.8mm | Human & Vehicle Detection, Built-in Mic Audio, IP67 IK10
Original price was: AUD $299.00.AUD $249.00Current price is: AUD $249.00. inc GST
Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome — a 6MP dome camera in white with a built-in microphone, an IK10 vandal-resistant aluminium alloy housing and powered-by-DarkFighter low light. Human and vehicle detection runs in the camera itself, and standard PoE brings power and video down one network cable.
📷 Wide View, With Detail to Zoom Into — 6MP at 3200 × 1800 from a 1/2.4″ sensor, through a 2.8 mm lens that takes in 114.8° across and 143.5° on the diagonal.
🌙 A Picture From Dusk Through to Darkness — colour down to 0.001 lux at F1.0 with AGC on, then black and white lit by its 850 nm IR supplement light out to 30 m.
🧠 Pick People, Vehicles or Both for Each Rule — deep-learning classification sorts targets into human and vehicle, and you choose, rule by rule, which of the two the camera responds to, or both.
🎙️ Listen Back to What Happened — One-way audio: the built-in microphone picks up sound at the camera; there is no built-in speaker. Pickup is mono, with environment noise filtering. Installers also get one audio line-in and one line-out terminal, and one alarm input and one alarm output.
⚪ White, Vandal-Resistant Housing — a vandal-resistant dome rated IK10 under IEC 62262:2002, its base and cover made of aluminium alloy and finished in white.
☀️ When the Sun Is Behind Your Visitor — 120 dB WDR, backed by BLC, HLC and 3D DNR, balances a bright background against a subject in shade.
💾 MicroSD slot — up to 512 GB — record onto a card inside the camera, with NAS and ANR as well; MicroSD card not included.
📡 No Power Point Needed at the Camera — the Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome is a PoE dome camera on standard PoE (802.3af), powered from a PoE switch or the PoE ports on a Hikvision NVR, with a separate DC supply as the other option.
🌧️ Rated for Rain, Dust, Frost and Summer Heat — IP67 water and dust resistant (IEC 60529-2013), working from -30 °C to 60 °C with humidity of 95% or less, non-condensing.
📱 See the Picture From Your Phone or Office PC — Hik-Connect on a phone, iVMS-4200 or Hik-Central on a computer, with up to 6 live-view channels.
🏆 Backed by Manufacturer Warranty — an Authorised Australian Product rather than a grey import.
Available models: DS-2CD2166G2H-ISU-280 (White, 2.8mm)
Hikvision brackets & mounts: the Hikvision bracket and junction box range
a 114.8° view across through an F1.0 lens · sound from the built-in microphone kept on the clip · an IK10 aluminium alloy housing that resists vandals · people and vehicles classified by deep learning · standard PoE from your Hikvision NVR or a PoE switch · a MicroSD slot for footage held in the camera
Shops, offices and strata blocks need a camera that stands up to a knock, while homes on a Hikvision recorder often want a low-light security camera that also listens. The Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome answers both: an IK10 vandal-resistant rating with an aluminium alloy base and cover, a microphone of its own, and people and vehicles classified on board, in a white housing.
The Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome puts a 2.8 mm F1.0 lens in front of a 1/2.4″ progressive scan CMOS that captures 3200 × 1800 at 25 fps (50 Hz), leaving room to zoom into a paused clip. Hikvision’s efficient H.265+ compression technology is one of its codecs, with H.265, H.264 and H.264+ also on the list.
Night Vision as Dusk Turns to Dark — Powered-by-DarkFighter Colour in Low Light, Infrared Out to 30 m
Your Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome is a night vision dome camera that works in two stages. While some light remains, powered-by-DarkFighter technology and the F1.0 lens keep the picture in colour down to 0.001 lux with AGC on. In darkness, the IR cut filter changes over, the image goes black and white, and the 850 nm IR supplement light lights the scene out to 30 m for a picture at 0 lux, with Smart Supplement Light listed on the sheet too.
Human and Vehicle Detection, Set Rule by Rule — Deep-Learning Classification for Line Crossing and Intrusion
The Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome uses human and vehicle classification based on deep learning, the AI detection Hikvision builds into the camera. On the sheet the rules are region exiting, region entrance, intrusion and line crossing, plus motion detection, and you set each one to people, vehicles or both. Once a rule fires, the dome can record, take a capture, email you, alert the surveillance centre, or save to FTP, a NAS or its memory card. Video tampering and scene change alarms run beside these rules. Vehicle detection classes a target as a vehicle; ANPR is not among this camera’s listed functions.
Hear What Happened on the Recording — Built-In Microphone, Mono, With Noise Filtering
A raised voice or a slammed door adds context a silent clip cannot give. If you are after a dome camera with microphone pickup built in, the Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome records mono sound through Hikvision’s built-in microphone for real-time audio security, with environment noise filtering applied. From that microphone the sound runs one way: the dome listens and records, and it has no speaker of its own.
One Cable to Run, a Housing Built to Resist Vandals — Standard PoE, IP67 and IK10, -30 °C to 60 °C
The Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome needs no power point beside it: standard PoE (802.3af) from a PoE switch or the PoE ports on a Hikvision NVR sends power and video along one network cable, and a separate DC supply can run it instead. Its housing is IK10 vandal-resistant under IEC 62262:2002 and IP67 water and dust resistant under IEC 60529-2013, with an aluminium alloy base and cover, rated from -30 °C to 60 °C. Four privacy masks blank out parts of the view you choose to keep off the recording.
Where the Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome Earns Its Place
🏡 Homes already running a Hikvision recorder — add the Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome over a single network cable, powered by a PoE-equipped NVR or a PoE switch, and its clips carry sound with the picture, colour down to 0.001 lux and infrared once it is dark.
🏢 Shops, offices and strata buildings — the Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome is vandal-resistant to IK10, picks up sound, and offers human and vehicle detection on its intrusion and line crossing rules.
🔧 Installers and electricians ordering by model code — the Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome has one audio line-in and one line-out terminal, and one alarm input and one alarm output, runs on standard PoE (802.3af), and comes from a Hikvision authorised partner.
The Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome in figures, from Hikvision’s datasheet for the 2.8mm model:
| Specification | Detail |
|---|---|
| Model | DS-2CD2166G2H-ISU (2.8mm) |
| Image Sensor / Resolution | 1/2.4″ Progressive Scan CMOS, 6MP (3200 × 1800) |
| Lens / Field of View | 2.8 mm fixed, F1.0, M12; horizontal 114.8°, vertical 60°, diagonal 143.5°; depth of field 1.7 m to ∞ |
| Minimum Illumination | Colour: 0.001 lux @ (F1.0, AGC on); B/W: 0 lux with IR |
| Day / Night | IR cut filter |
| Infrared | IR supplement light, up to 30 m, 850 nm; Smart Supplement Light: Yes |
| DORI (2.8mm) | Detect 64 m · Observe 25 m · Recognise 12 m · Identify 6 m |
| Wide Dynamic Range | 120 dB; BLC, HLC, 3D DNR |
| Video Compression / Frame Rate | H.265 / H.264 / H.264+ / H.265+ (main stream); 25 fps at 3200 × 1800 (50 Hz) |
| Smart Events | Human and vehicle classification (deep learning); motion detection with alarm triggering by target type (human and vehicle); line crossing, intrusion, region entrance and region exiting; video tampering alarm; scene change detection; Face Capture: Yes |
| Event Linkage | Upload to FTP/NAS/memory card, notify surveillance center, trigger recording, trigger capture, send email |
| Audio | Built-in microphone, mono, environment noise filtering; no speaker |
| Audio and Alarm Terminals | One audio line-in and one line-out terminal (two-core terminal blocks); one alarm input and one alarm output (max. 12 VDC, 30 mA) |
| On-Board Storage | MicroSD slot — up to 512 GB — MicroSD card not included; NAS; ANR |
| Network / Integration | 1 × RJ45 10 M/100 M; ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP; up to 6 live-view channels |
| Power | PoE (IEEE 802.3af, Class 3), max. 9.5 W; or 12 VDC ± 25%, 0.65 A, max. 7.8 W, Ø5.5 mm coaxial plug |
| Housing / Protection | IP67 (IEC 60529-2013) water and dust resistant; IK10 (IEC 62262:2002) vandal-resistant; aluminium alloy base and cover |
| Angle Adjustment | Pan 0° to 355°, tilt 0° to 75°, rotate 0° to 355° |
| Privacy Masks | 4 |
| Operating Conditions | -30 °C to 60 °C, humidity 95% or less (non-condensing) |
| Dimensions / Weight | Ø121.5 mm × 97.6 mm; approx. 525 g |
| Apps and Software | Hik-Connect, iVMS-4200, Hik-Central |
Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome vs Hikvision DS-2CD2366G2H-IU — Dome or Turret, and What the Dome Adds
| What differs | Hikvision DS-2CD2166G2H-ISU dome (this product) | Hikvision DS-2CD2366G2H-IU turret |
|---|---|---|
| Housing | Fixed dome | Fixed turret |
| IK10 vandal rating | IK10 (IEC 62262:2002) | Not listed on its datasheet |
| Audio and alarm terminals | One audio line-in and one line-out terminal; one alarm input and one alarm output | None listed on its datasheet |
| Housing colour | White | Black, or white as DS-2CD2366G2H-IU-0280 |
Both cameras share the 1/2.4″ sensor at 3200 × 1800, the F1.0 2.8 mm lens with its 114.8° horizontal view, infrared to 30 m and a built-in microphone. The Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome adds the IK10 vandal rating and the audio and alarm terminals in a white housing, while the turret comes in black, or in white as the DS-2CD2366G2H-IU-0280.
Frequently Asked Questions — Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome
Q: Will this work as a camera for my Hikvision NVR?
A: The Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome works with current model Hikvision NVRs; one with PoE ports records it and powers it over standard PoE (802.3af). A PoE switch or a separate DC supply can power it instead, and the power row in the table above gives the figures.
Q: Can a recorder from another brand run it?
A: It supports ONVIF Profiles S, G and T; ONVIF compliance does not guarantee full feature support on third-party systems.
Q: Does the dome record sound, and is there a speaker?
A: One-way audio: the built-in microphone picks up sound at the camera; there is no built-in speaker. Sound is recorded in mono with environment noise filtering.
Q: What does the picture look like as daylight fades?
A: It stays in colour down to 0.001 lux (F1.0, AGC on). Once it is dark, the camera switches to black and white and its IR supplement light reaches 30 m at 850 nm, with Smart Supplement Light listed.
Q: Can it record to a card in the camera, and is one included?
A: The dome takes a card of your choice: MicroSD slot — up to 512 GB. MicroSD card not included, so add one in the size you want.
Q: Does the human and vehicle detection run in the camera or in the recorder?
A: In the camera. The dome classifies targets as human or vehicle by deep learning on board, and the line crossing, intrusion and region rules are the dome’s own.
Build a Complete Hikvision System, Dome to Recorder
This dome records to, and draws power from, a PoE recorder: see our Hikvision NVR range. Wire it on Cat6 unshielded cable, add more 6MP cameras through our Hikvision 6MP IP camera range, and fit it on a Hikvision bracket or junction box.
The white Hikvision DS-2CD2166G2H-ISU 6MP DarkFighter dome is part of the Hikvision 6MP IP Cameras range we carry as genuine Hikvision product for Australia, and this dome ships from our Melbourne and Sydney warehouses.
