AXIS S2224 Mk II 24-Channel 12TB NVR Recorder with PoE Switch + AXIS Camera Station Pro Licences – 02810-006
AUD $9,064.00 inc GST
All-in-one 24-channel Axis S2224 Mk II rack recorder with 12 TB surveillance storage, integrated 24-port PoE switch, and AXIS Camera Station Pro software. Designed for professional, scalable CCTV installations with secure boot, TPM 2.0 encryption, and a 5-year Axis warranty. Ideal for commercial and critical infrastructure security systems.
AXIS S2224 Mk II 24-channel NVR recorder with 12 TB HDD storage, 24 × PoE ports, and AXIS Camera Station Pro software pre-installed. Supports AI analytics and secure boot with FIPS 140-2 TPM 2.0. Rack-mount 1U design with 16 GB RAM and Intel Core i3 processor for smooth multi-stream recording and playback.
Axis S2224 MKII Camera Station Rack Appliance.
This 24-channel rack appliance includes everything you need to run your complete surveillance system such as AXIS Camera Station Pro licenses, a 24-port PoE switch, and 12 TB of storage. It comes with pre-loaded software and tools to minimize installation time.
– All-in-one solution with integrated PoE switch
– 24 AXIS Camera Station Pro licenses included
– Room for storage expansion
– Advance Replacement Service and 5-year hardware warranty
– High cyber security features and standards
02810-006 Datasheet: 220825043723-datasheet-axis-s2224-mk-ii-rack-appliance-en-US-485798
AXIS S2224 Mk II 24-Channel 12 TB Product Video:
Professional-Grade All-in-One Recording Solution
The AXIS S2224 Mk II Rack Appliance is a purpose-built NVR designed for professional surveillance networksdemanding high reliability, scalability, and performance. With AXIS Camera Station Pro software pre-installed, it’s ready to deploy straight out of the box — just add your Axis IP cameras.
Key Highlights
🎥 24 × AXIS Camera Station Pro licences included (expandable)
💾 12 TB surveillance-class HDDs (2 × 6 TB) with 4 drive bays and RAID support (0/1/10)
🔌 Integrated 24-port PoE switch (260 W total budget, IEEE 802.3at Class 4)
🧠 Intel Core i3 processor + 16 GB DDR5 RAM for smooth multi-stream operation
💡 8 K + 4 K monitor support for advanced live view and playback
🔐 FIPS 140-2 Level 2 TPM, Secure Boot, and Signed Firmware for enterprise-grade cybersecurity
🧱 1U rack-mount design with quiet operation and robust build quality
🛡 5-year Axis hardware warranty + Advance Replacement Service
⚙️ Technical Overview
| Feature | Specification |
|---|---|
| Processor | Intel® Core™ i3 |
| Memory | 16 GB DDR5 (2× 8 GB) |
| Storage | 12 TB (2× 6 TB Surveillance HDD), 4 slots total |
| RAID Support | 0, 1, 10 |
| Network Switch | 24 × PoE (260 W total budget), 1 × SFP 1 Gbps |
| Video Throughput | Up to 384 Mbps recording rate (24 channels) |
| Display Support | 1 × 8 K @ 20 fps or 2 × 4 K monitors @ 30 fps |
| Operating System | Windows 11 IoT Enterprise LTSC 2024 |
| Operating Temp | 0 °C to 40 °C |
| Dimensions | 476 × 440 × 45 mm (1 U rack) |
| Weight | 11 kg |
| Warranty | 5 Years (Recorder + HDDs) |
💡 How Can This Product Help?
Simplifies deployment — preloaded with AXIS Camera Station Pro for plug-and-play setup.
Reduces infrastructure costs — integrated 24-port PoE switch means no separate PoE hardware needed.
Delivers enterprise-level security with TPM, secure boot chain, and digitally signed firmware.
Ideal for medium to large installations — support for 24 cameras and 48 doors in hybrid video/access systems.
Scalable architecture — expand with AXIS S30 Recorder Series for future growth.
Future-proof AI integration — supports AXIS Smart Search 2 and AI applications.
📦 Included Accessories
Rack rails and power cord
AXIS Camera Station Pro licences (24 included)
Pre-installed Windows 11 IoT Enterprise
Quick setup wizard and Recorder Toolbox
Please Note
This recorder is designed for use with AXIS network cameras and devices.
Third-party camera integration may be limited and should be verified before purchase.
Additional information
| Weight | 6 kg |
|---|---|
| Dimensions | 19 × 53 × 19 cm |
